Jib Cranes
Articulating Jib Crane
Flexible articulating jib crane for compact workstation lifting, corner-reaching handling, and machine-side material positioning.
- Rated Lifting Capacity
- Up to 1 t
- Arm Length
- Up to 5 m
- Rotation Angle
- 120°-360°
- Control Mode
- Floor control / Remote control
Product Overview
Articulating Jib Crane is designed for flexible material handling in areas where traditional jib cranes cannot easily reach. Its articulated arm structure helps position loads around corners, into machines, and across compact workstation areas with smooth and responsive operation.
This crane is suitable for production, maintenance, and machine-side lifting tasks in industries such as machinery manufacturing, railway, chemical processing, and light industry. It can support frequent local handling where operators need flexible movement and accurate load positioning.
For more related lifting solutions, you can view our Jib Crane category, including Wall Mounted Jib Crane, Wall Travelling Jib Crane, and Free Standing Jib Crane.
Technical Parameters
| Parameter | Value |
|---|---|
| Lifting Height | Up to 4 m |
| Work Duty | M3-M5 |
| Rated Voltage | 220V~690V, 50-60Hz, 3ph AC |
| Installation Position | Wall mounting or plant column mounting |
| Hoist Option | Chain hoist or micro-hoist |
| Application | Machinery manufacturing, railway, chemical, light industry, production and maintenance lines |
Key Features
Helps reach corners, machines, and confined workstation areas
Suitable for frequent local lifting operations
Can be installed on wall structures or plant columns
Flexible workstation coverage with easy movement
Precise load positioning and convenient operation
Lightweight structure and easy installation
Suitable for production and maintenance lines
Customized Crane Solution
Articulating Jib Crane can be customized according to workstation layout, installation structure, operation habit, load positioning requirement, and local handling process.
Available customization includes arm configuration, mounting method, hoist selection, electrical arrangement, surface finish, and workstation lifting solution design.
- Customized articulated arm configuration
- Wall-mounted or column-mounted installation layout
- Customized hoist selection according to handling needs
- Customized electrical and operation arrangement
- Customized solution for machine-side material handling
You may also compare this product with Balance Jib Crane, Wall Mounted Jib Crane, and Free Standing Jib Crane for different workstation lifting requirements.
Get a Factory-Based Quotation
Send your capacity, span, lifting height and working site. Our team will help check the suitable crane type and provide a project-based quotation.
Parameter Check
We review capacity, span, lifting height, duty and site conditions before recommending a configuration.
Factory Configuration
Quotation is based on crane structure, hoist or trolley type, control system and safety options.
Export Support
Discuss packing, delivery reference, drawings and project communication for overseas orders.
What We Need
- Capacity, span, lifting height and working duty.
- Workshop or yard layout, runway condition and power supply.
- Working environment, daily operation time and special requirements.
- Destination country, quantity and drawings or photos if available.
How It Works
- Send parametersShare the project data you already know.
- Confirm configurationWe check crane type and key technical scope.
- Receive quotationGet factory-based price and selection support.
