Wire Rope Drum
Wire Rope Drum is a key crane spare part used for winding wire rope and supporting safe lifting, lowering, and pulling operations in crane and hoist systems.
- Material
- 20#, Q235, Q345
- Groove Hardness
- HRC45-55
- Groove Quench Depth
- ≥2mm
- Heat Treatment
- Hardening, tempering, high-frequency quenching
- Inspection
- UT and MT available
- Applications
- Overhead cranes, gantry cranes, hoists, winches, port cranes
Product Overview
Wire Rope Drum, also known as crane drum or hoist drum, is an essential component in lifting machinery. It is used to wind and guide wire rope during lifting, lowering, and pulling operations, helping cranes, hoists, winches, and other lifting equipment move loads smoothly and safely.
The drum is commonly used in single girder overhead cranes, double girder overhead cranes, gantry cranes, port cranes, ship winches, beam lifting machines, winches, three-dimensional garages, and other lifting systems. A proper drum design helps maintain wire rope arrangement, reduce uneven winding, and support stable transmission during crane operation.
Wire Rope Drum for Crane Lifting Systems
A typical crane drum can include drum shaft, flange, annular gear, drum hub, bearings, bearing pedestal, and groove surface. According to the lifting mechanism and rope arrangement, the drum can be designed as smooth drum, spiral groove drum, single drum, double drum, or special groove drum for specific lifting applications.
For demanding lifting applications, the groove surface can be quenched and heat treated to improve hardness, wear resistance, and service life. Material, groove form, drum diameter, shaft arrangement, heat treatment, inspection method, and mounting structure should be selected according to lifting capacity, rope diameter, lifting height, speed, working duty, and equipment type.
For related lifting equipment, you can also view Overhead Cranes, Gantry Cranes, and Electric Hoists. For wire rope, drum and crane safety reference, you may check the ISO 16625 Cranes and Hoists — Selection of Wire Ropes, Drums and Sheaves, OSHA Overhead and Gantry Cranes Safety Standard, and ASME B30.2 Overhead and Gantry Cranes.
